Applicable scope:
Foods, chemicals, pharmaceutical products, cosmetics, electronics, hardwares, auto parts,stationery items, batteries, cartons, different kinds of oil, and packaging of various specifications that needed three-sided labeling.
Features:
1.Three-sided labeling with a label.
2.Vacuum label suction of labels to control label feeding and accurate labeling,
and labeling accuracy of ±0.5mm.
3.Proper control on glue film thickness to avoid peeling and glue omission
(available in optional water glue and hot melt adhesive); labeling accuracy is
±0.5mm.
4.Applicable with labels in lithographic paper, coated paper, lacquered paper or
foil paper.
5.A conveyor belt structure can be directly connected on the front and rear of
production line.
6.Labeling cost reduction.
7.Universal label holder to accommodate different label sizes and shapes, and five-
minute quick adjustment.
8.Labeling speed: 30 ~ 50 bottles/min.
Applicable products :

| Machine dimensions | 1800 x 1200 x 1600 mm (L x W x H) |
| Machine weight | 600 kg |
| Maximum labeling size | (standard type) 180 x 160mm (L x W):(widen type) 280 x 160mm (L x W) |
| Power rating | 3-phase220V 50 / 60 HZ |
| Dry compressed air | 6~8kg/cm2 |
